ARX-G310 Continuous Monitoring System for Smoke Emissions Introduction: ARX-G310 is a new CEMS system launched by the company, equipped with a UV analyzer that can directly measure NO2 function, solving the pain point of insufficient efficiency of some on-site nitrogen oxide converters, reducing the cost of replacing molybdenum furnace consumables, and optimizing costs for users. System composition: 1. Monitoring unit for gaseous pollutants (SO2, NOx) Using AGA1000-UV ultra-low online flue gas analyzer, based on the principle of ultraviolet differential, nitrogen oxide converter or UV analyzer with direct NO2 measurement function can be selected to measure SO2, NOx, O2 simultaneously; The matching integrated high-temperature sampling probe is equipped with a built-in flue gas filter, which has sampling, calibration, and blowback functions. It is easy to disassemble and maintain, and can effectively ensure long-term operation without blockage. 2. Particle monitoring unit The standard configuration of the system is the LSS2004 laser backscatter particle analyzer. According to different operating conditions, optional particle concentration analyzers such as LFS800 (extraction type) and LSS2014 (in-situ type) are selected. The above products have all obtained CCEP environmental certification. 3. Smoke parameter monitoring unit According to different operating conditions, APT2000, UF2020 and other flue gas parameter measuring instruments are configured to measure flue gas temperature, flow rate, pressure, and humidity. Reliable connection of valve groups and sensors in the host air circuit to avoid air leakage and other faults caused by aging and rupture of the trachea; More compact structure and smaller size for on-site installation and maintenance. 4. Data collection and processing unit The system control software running on the main control computer completes the collection, data storage, display and presentation of various subsystem parameters, and has functions such as automatic fault diagnosis, report generation, and historical record query. External interface: Provide rich interfaces for data transmission to the environmental protection administrative department's fixed source emission monitoring system, pollution control facility operation monitoring system, DCS system, etc. Features: 1. The environmental certification testing report is based on the (new) HJ 76-2017 standard, with a certification range of 0-45 mg/m3; 2. Innovative interference cancellation technology has achieved extremely low zero drift and range drift over a wide temperature range; 3. The patented ultra-low algorithm and spectral equalization technology (patent number: ZL 2017 1 1259438.1) have a minimum detection limit of 0.05mg/m3 for SO2 and NO; 4. The patented integrated high-temperature flue gas sampling probe (patent number: ZL 2020 2 2457227.2) is equipped with a built-in high-temperature resistant flue gas filter; 5. Key components, using imported pulsed xenon lamp light source and imported high-sensitivity spatial coupling spectrometer; 6. The full space coupling optical path solves the problem of UV fiber aging and vulnerability; The light transmittance is not affected by aging, temperature, and vibration changes, improving work stability; 7. Support fully automatic calibration (zero point, range), freely set calibration cycle, without personnel intervention; 8. Built in fault self diagnosis module, providing a visual interface, can quickly, accurately, and deeply locate faulty modules and components after a fault occurs, greatly reducing system maintenance time; 9. It is possible to choose to configure a nitrogen oxide converter or a UV analyzer with direct NO2 measurement function.
Introduction: ARX-G310 is a new CEMS system launched by the company, equipped with a UV analyzer that can directly measure NO2 function, solving the pain point of insufficient efficiency of some on-site nitrogen oxide converters, reducing the cost of replacing molybdenum furnace consumables, and optimizing costs for users.
