UV-II type UV irradiated cable cross-linking equipment Introduction: The process flow of UV irradiation cable cross-linking equipment is to use UV light as the radiation source, extrude and wrap the mixed photo cross-linked polyolefin ingredients on the conductive wire core, and then immediately enter a specially designed irradiation equipment for molten photo cross-linking. The insulated wire core crosslinked by light irradiation can be processed by cooling at different temperatures and subsequent processing to obtain light crosslinked polyolefin insulated wire and cable products. The UV irradiated cable cross-linking equipment only needs to be slightly modified on the original ordinary extrusion production line, and can meet the usage requirements by placing small-sized upper traction, irradiation boxes, electrical control cabinets, etc., to produce UV irradiated cross-linked polyethylene wire and cable products. The UV irradiation cable cross-linking equipment mainly consists of four parts: the irradiation main box, the intake/exhaust fan unit, the control cabinet, and the lamp source power supply cabinet. Technical parameters: Name: UVL-II Equipment total installed power: 15kW Effective diameter of irradiation area: 30mm Effective irradiation length: 1m Light source lifespan: 40000 hours (provided by the light source manufacturer) Chiller power: 4kW Temperature control range: 5-35 ℃ Compressor horsepower: 8HP Radiation box size: 1500 * 1300 * 1615mm
Introduction: The process flow of UV irradiation cable cross-linking equipment is to use UV light as the radiation source, extrude and wrap the mixed photo cross-linked polyolefin ingredients on the conductive wire core, and then immediately enter a specially designed irradiation equipment for molten photo cross-linking. The insulated wire core crosslinked by light irradiation can be processed by cooling at different temperatures and subsequent processing to obtain light crosslinked polyolefin insulated wire and cable products. The UV irradiated cable cross-linking equipment only needs to be slightly modified on the original ordinary extrusion production line, and can meet the usage requirements by placing small-sized upper traction, irradiation boxes, electrical control cabinets, etc., to produce UV irradiated cross-linked polyethylene wire and cable products. The UV irradiation cable cross-linking equipment mainly consists of four parts: the irradiation main box, the intake/exhaust fan unit, the control cabinet, and the lamp source power supply cabinet.
