ZRT-B Thermal Adsorption Analyzer for Nanomaterials Research

Product ID:WLrz023

US$0.00 ~ US$1.00 PDF Format
Supply Ability:50 SETS/MON
Port:SHENZHEN
share:
  • Product Introduction
  • Consulting
  • Model NumberZRT-B
    Brand NameJINGYIGAOKE
    Payment TermsTT,PAYPAL
    ZRT-B Thermal Adsorption Analyzer

    Introduction:
          The sample is subjected to varying humidity, gas and temperature conditions and the response of the sample is measured gravimetrically. The instrument can display the whole process of adsorption and desorption. ZRT-B thermal adsorption analyzer studies the following properties of materials: The properties measured by thermogravimetric method include corrosion, high temperature decomposition, adsorption/desorption, loss of solvent, oxidation/reduction reaction, hydration/dehydration, decomposition, black smoke Wait. Product application: The instrument is widely used in petrochemical, chemical and chemical, energy, biology, food, medicine and health, surface metal and nanomaterials, automobile exhaust, chemical waste gas conversion and treatment and other aspects of research.
    Features:
    1. The furnace body of the instrument automatically rises and falls, which is easy to operate
    2. The furnace body adopts the lower plate structure, which can pass water vapor and corrosive gas
    3. The sample crucible adopts a large-diameter crucible, so that a larger area of ​​the sample is in contact with the reaction gas
    4. The instrument data is collected by computer, the software interface is friendly, and it is suitable for win7, win8, win10 operating systems
    Technical parameter:
    Product model: ZRT-B type
    Temperature range: room temperature -1450 degrees
    Heating rate: 0.1~100/min
    Cooling rate: 0.1~40/min
    Temperature Sensitivity: 0.1
    Thermogravimetric range: 1-200mg, replace the support rod up to 5g
    Thermogravimetric sensitivity: 0.1ug
    Thermogravimetric accuracy: 1ug
    Thermal Gravity Noise: <1ug
    Thermogravimetric Differential Range: 1-100mg/min
    Auto-zero range: 0999mg
    Vacuum degree: 2.66X10-2Pa
    Atmosphere control: dual-channel voltage stabilization and steady flow control, (various corrosion-resistant atmosphere control systems can be customized)
    Crucible: Standard alumina 0.06ml or 0.12ml, optional aluminum crucible, copper crucible, platinum crucible, quartz crucible, graphite crucible
    Constant temperature water bath (optional): temperature accuracy ±0.1
    Thermostat controller (optional): mass spectrometer connector, controller temperature range 0~400
    Output method: brand computer, laser printer
  • Introduction:
          The sample is subjected to varying humidity, gas and temperature conditions and the response of the sample is measured gravimetrically. The instrument can display the whole process of adsorption and desorption. ZRT-B thermal adsorption analyzer studies the following properties of materials: The properties measured by thermogravimetric method include corrosion, high temperature decomposition, adsorption/desorption, loss of solvent, oxidation/reduction reaction, hydration/dehydration, decomposition, black smoke Wait. Product application: The instrument is widely used in petrochemical, chemical and chemical, energy, biology, food, medicine and health, surface metal and nanomaterials, automobile exhaust, chemical waste gas conversion and treatment and other aspects of research.
