ZD-2 Automatic Potentiometric Titrator

Position: Home > > Analytical instruments > Electrochemical Equipment > Potentiometric titration > ZD-2 Automatic Potentiometric Titrator

ZD-2 Automatic Potentiometric Titrator

Product ID：FDdd008

Price: Please inquire PDF Format

Supply Ability:60 SETS/MON

Port:SHENZHEN

Product Introduction
Other information

Model NumberZD-2

Brand NameSHYIDIAN

Payment TermsTT，PAYPAL，Alibaba.com Pay

ZD-2 Automatic Potentiometric Titrator
Product Overview
The ZD-2 Automatic Potentiometric Titrator is a reliable and economical analytical instrument designed for accurate potentiometric titration in laboratory environments. The system automatically detects titration endpoints based on preset pH or potential values, ensuring high precision and repeatability while reducing operator intervention.
Featuring manual, automatic, and constant pH (potential) titration modes, the ZD-2 is suitable for a wide range of analytical applications including acid-base titration, redox titration, precipitation titration, and routine chemical analysis. Its magnetic valve-controlled dosing system provides stable titrant delivery and improves titration accuracy.

Key Features
•  Automatic endpoint control based on preset pH or potential values
•  Supports pH and mV measurement modes
•  Manual, automatic, and constant pH (potential) titration functions
•  Adjustable pre-control potential (pH) setting
•  Magnetic valve control for precise titrant dispensing
•  Built-in endpoint delay circuit for improved endpoint determination
•  Stable 0–1 mV analog output signal
•  High measurement accuracy and repeatability
•  Simple operation and cost-effective laboratory solution
•  Suitable for routine quality control and research applications

Working Principle
The ZD-2 Automatic Potentiometric Titrator measures changes in electrode potential (mV) or pH during the titration process. As titrant is added to the sample solution, the instrument continuously monitors the electrochemical response through the electrode system.
When the measured value reaches the preset endpoint potential or pH value, the titrator automatically controls the titration process through its magnetic valve system. This automated endpoint detection minimizes human error and improves analytical consistency and reproducibility.

Technical Specifications

Parameter	Specification
Model	ZD-2
pH Measurement Range	0.00 – 14.00 pH
mV Measurement Range	0 – ±1400 mV
pH Resolution	0.01 pH
mV Resolution	1 mV
pH Accuracy	±0.03 pH ±1 bit
mV Accuracy	±5 mV ±1 bit
Input Impedance	3 × 10¹¹ Ω
Stability	±0.01 pH / 3 h
Endpoint Control Accuracy	±0.1 pH or ±5 mV ±1 bit
Volume Analysis Repeatability	0.2%
Titration Modes	Manual, Automatic, Constant pH/Potential
Titration Speed Control	Magnetic Valve
Output Signal	0–1 mV

Applications
The ZD-2 Automatic Potentiometric Titrator is widely used in:
•  Acid-base titration
•  Redox titration
•  Precipitation titration
•  Water quality analysis
•  Chemical laboratory testing
•  Pharmaceutical quality control
•  Food and beverage analysis
•  Environmental monitoring
•  Petrochemical laboratories
•  Educational and research institutions
•  Industrial process control laboratories

Comparison

Feature	ZD-2 Automatic Potentiometric Titrator	Manual Titration Method
Endpoint Detection	Automatic	Visual Observation
Accuracy	High	Operator Dependent
Repeatability	Excellent	Moderate
Titration Speed Control	Automatic Magnetic Valve	Manual
Constant pH Titration	Supported	Not Available
Labor Requirement	Low	High
Human Error Risk	Minimal	Higher
Data Consistency	Excellent	Variable

Frequently Asked Questions (FAQ)
1. What types of titration can the ZD-2 perform?
The ZD-2 supports acid-base titration, redox titration, precipitation titration, and other potentiometric titration applications.
2. Does the instrument support automatic endpoint detection?
Yes. The titrator automatically controls the endpoint based on preset pH or potential values.
3. What measurement parameters are available?
The instrument measures both pH and mV (electrode potential) values.
4. What titration modes are included?
The ZD-2 offers manual titration, automatic titration, and constant pH (potential) titration modes.
5. How is titration speed controlled?
A built-in magnetic valve automatically regulates titrant flow to improve dosing precision.
6. What is the repeatability of volume analysis?
The instrument provides excellent repeatability with a volume analysis reproducibility of 0.2%.
7. Is the ZD-2 suitable for quality control laboratories?
Yes. Its high accuracy, repeatability, and automatic endpoint control make it ideal for routine QC testing.
8. Can the instrument be used in educational laboratories?
Yes. The simple operation and intuitive titration process make it suitable for teaching, training, and academic research.
9. What advantages does potentiometric titration offer compared with manual titration?
Potentiometric titration improves accuracy, reduces operator influence, provides automatic endpoint determination, and enhances analytical reproducibility.

Why Choose the ZD-2 Automatic Potentiometric Titrator?
The ZD-2 Automatic Potentiometric Titrator combines reliable potentiometric measurement, automatic endpoint detection, and precise titrant control in a cost-effective laboratory instrument. With support for multiple titration modes, excellent measurement stability, and high analytical repeatability, it is an ideal solution for routine chemical analysis, quality control, environmental testing, and scientific research laboratories.

Frequently Asked Questions (FAQ)
1. What types of titration can the ZD-2 perform?
The ZD-2 supports acid-base titration, redox titration, precipitation titration, and other potentiometric titration applications.
2. Does the instrument support automatic endpoint detection?
Yes. The titrator automatically controls the endpoint based on preset pH or potential values.
3. What measurement parameters are available?
The instrument measures both pH and mV (electrode potential) values.
4. What titration modes are included?
The ZD-2 offers manual titration, automatic titration, and constant pH (potential) titration modes.
5. How is titration speed controlled?
A built-in magnetic valve automatically regulates titrant flow to improve dosing precision.
6. What is the repeatability of volume analysis?
The instrument provides excellent repeatability with a volume analysis reproducibility of 0.2%.
7. Is the ZD-2 suitable for quality control laboratories?
Yes. Its high accuracy, repeatability, and automatic endpoint control make it ideal for routine QC testing.
8. Can the instrument be used in educational laboratories?
Yes. The simple operation and intuitive titration process make it suitable for teaching, training, and academic research.
9. What advantages does potentiometric titration offer compared with manual titration?
Potentiometric titration improves accuracy, reduces operator influence, provides automatic endpoint determination, and enhances analytical reproducibility.
