Application scope: It is suitable for measuring vibration acceleration, velocity and displacement of various rotating machines. Basic functional test scope of technical indicators: Vibration displacement (P-P) : 0-1999 microns Vibration speed (RMS) : 0~199.9mm/s Vibration acceleration (o-p) : 0~199.9m/s Frequency response range and amplitude error: Vibration displacement (p-p):10~200Hz, less than or equal to 10% Vibration speed (RMS):10~500Hz, less than or equal to 10% Vibration acceleration (o-p):10~1000Hz, less than or equal to 10% Linear amplitude error: Vibration displacement :0 to 20 microns, less than or equal to 10%, more than or equal to 20 microns, less than or equal to 5% Vibration speed (RMS):0~2.0mm/s, less than 10%, > 2.0mm/s, less than 5% Vibration acceleration (o-p):0~2.0m/s, less than or equal to 10% >, 2.0m/s, less than or equal to 5% Special functions: Low voltage display: the battery voltage is lower than 5.5v, and a low voltage prompt is displayed. The battery should be replaced at this time. Data holding time: when the measurement key is released, the measured data can be kept for one minute. Indicator fluctuation: indicator indicates that the fluctuation is not greater than one resolution. Using the environment temperature: 0 ~ 40 ℃ Ambient humidity: no more than 80% Atmospheric pressure :75~106kpa Size: 185 x 68 x 30 mm Weight :230g(including battery) Power supply: 9 v (6) making
Basic functional test scope of technical indicators: Vibration displacement (P-P) : 0-1999 microns Vibration speed (RMS) : 0~199.9mm/s Vibration acceleration (o-p) : 0~199.9m/s Frequency response range and amplitude error: Vibration displacement (p-p):10~200Hz, less than or equal to 10% Vibration speed (RMS):10~500Hz, less than or equal to 10% Vibration acceleration (o-p):10~1000Hz, less than or equal to 10% Linear amplitude error: Vibration displacement :0 to 20 microns, less than or equal to 10%, more than or equal to 20 microns, less than or equal to 5% Vibration speed (RMS):0~2.0mm/s, less than 10%, > 2.0mm/s, less than 5% Vibration acceleration (o-p):0~2.0m/s, less than or equal to 10% >, 2.0m/s, less than or equal to 5%
