| Voltage | AC 110V and 208-240V (50/60Hz) switchable for worldwide operation. |
| Power | 400W |
| Two Super Flat Lapping Plate | Flatness< 0.25 micron / Inch² |
| Precision Rotating Shaft | Running off < 5 micron |
| Features | One cast iron plate for lapping and one cast aluminum plate forpolishing Heavy duty cast aluminum case with bright painting Three rocking work stations with wafer holders and condition rings. They can be controlled independently for polishing 3 pcs of 4" wafers or 9 pcs of 2" wafers in one running |
| Adjustable Timer for Auto-stop | 0~99 hours |
| Variable Speed | 0 to 80 RPM with digital display |
| Optional Accessories | Consumables for polishing/lapping/grinding (sand paper, pad, plate, slurry, molding, coolant, etc) Accessory equipment (slurry feeder, carrier/chuck, thickness meter, weights, etc) 4" Polishing Fixture With Pressure Indicator for Precision / Automatic Thinning and Polishing- EQ-PF-4-1P is available at extra cost |
| Compliance | CE Certified MET Certification (UL 73 Standard) is available upon request at extra cost. Please contact our sales representatives for a price quote. |
Please inquire
