TG-C1 thermogravimetric analyzer

Product ID：WLrz034

Price: Please inquire PDF Format

Supply Ability:50 SETS/MON

Port:SHENZHEN

Product Introduction
Other information

Model NumberTG-C1

Brand NameBJKERUIOU

Payment TermsTT，PAYPAL，Alibaba.com Pay

TG-C1 thermogravimetric analyzer
Introduction:
Adopting a new design concept, collaborating with advanced foreign technologies to jointly develop a seriesof thermal analysis products; The TG-C thermogravimetric analyzer can test materials including high molecular weight polymers, coatings, petrochemicals, ceramics, glass, insulation materials, metals, drugs, and various other solid, liquid, paste, or powder materials; The application scope is very wide, such as material research and development, performance testing, and quality control.
characteristic:
1.Imported high-precision photoelectric balance technology, with a resolution of up to 0.002 μ g, can provide extremely high sensitivity and reliability
2.Design the upper balance to reduce buoyancy effects; Hanging samples to eliminate torque effects
3.The furnace body adopts a water-cooled cycle for rapid cooling, which can be controlled by a program for temperature rise and fall or constant temperature operation
4.The bottom of the furnace is equipped with an independent temperature control module for precise temperature control
5.Built in electromagnet for Curie point temperature calibration, based on ASTM E1582 standard
6.Customize CALISTO 2.0 professional thermal analysis software
7.Manufacturer's R&D engineers provide more professional and efficient after-sales technical services
Technical parameters:

temperature range	RT-1100℃
Temperature control rate	0.01—50 k/min
Temperature accuracy	± 0.3℃
Temperature Accuracy	±0.1℃
Dynamic weighing range	±20 ; ± 200（mg）
resolution	0.002μg
Weighing accuracy	0.01%
Weighing accuracy	0.005%
baseline drift	＜25μg
Baseline repeatability	±5μg
Atmosphere	Inert gases (N2, Ar, He...)or oxidizing atmospheres (air, O2...)
outline dimension	650-400-500（mm）

Introduction:
Adopting a new design concept, collaborating with advanced foreign technologies to jointly develop a seriesof thermal analysis products; The TG-C thermogravimetric analyzer can test materials including high molecular weight polymers, coatings, petrochemicals, ceramics, glass, insulation materials, metals, drugs, and various other solid, liquid, paste, or powder materials; The application scope is very wide, such as material research and development, performance testing, and quality control.
