HGCT-1 Ultra-High Temperature Differential Thermal Balance

Product ID：WLtb017

Price: Please inquire PDF Format

Supply Ability:50 SETS/MON

Port:SHENZHEN

Product Introduction
Other information

Model NumberHGCT-1

Brand NameBJHENGJIU

Payment TermsTT，PAYPAL，Alibaba.com Pay

HGCT-1 Ultra-High Temperature Differential Thermal Balance
Introduction:
Test the material properties of substances under ultra-high temperature conditions, as well as the reaction rate, reaction kinetics, activation energy, etc. between different reacting substances under ultra-high temperature conditions; application areas: aviation, aerospace, metal smelting, and other industries.
Features:
1. Adopting a brand-new double-helix graphite heating furnace design, achieving a heating temperature of ≥1700℃. It features a long temperature uniformity zone, long service life, and easy maintenance;
2. The vacuuming or inert gas filling process within the furnace body is fully automated, with one-click operation;
3. Test atmosphere: oxidation, reduction, inert, water vapor;
4. Evolved gas analysis: dedicated mass spectrometer, infrared isothermal connector, connecting belt, and isothermal controller;
5. Improved data acquisition and analysis functions; real-time data analysis, multiple curve comparisons, evaluation data saving and exporting; ASCII data input and output, data exporting to MS Excel for text program editing; power-off data saving function, 64-segment temperature control program, and experimental cycle times up to 999.
Technical Specifications:

temperature data		Balance data
temperature range	Room temperature - 1700℃ (Room temperature - 2200℃, Room temperature - 2400℃, Room temperature - 3000℃)	Mechanical zero-position photoelectric balance
temperature range		Thermal weight range	1-200mg (adjustable from 0-5g by replacing the support rod)
Temperature accuracy	±0.1℃	Balance sensitivity	0.1μg
Heating and cooling rate	0.1℃/min-200℃/min	Thermogravimetric noise	<0.1μg
DSC data		Differential thermal data
DSC range	0-±500mW	DTA range	±2000μV
DSC accuracy	±0.1μW	resolution	0.01μV
calibration parameters	In response ratio: 100mW/K	Sample atmosphere	Oxidation, reduction, inertness, vacuum
Enthalpy accuracy	±0.1%(In)	Standard Configuration	Ceramic crucible 0.06ml or 0.12ml
Temperature/enthalpy correction	Multiple standard samples, nonlinear calibration technique	Optional crucible	Aluminum crucible, graphite crucible, quartz crucible, platinum crucible
