FC-9624YL Automatic Water Sampler

Product ID:HSCcy002

Price: US$4,000.00 ~ US$5,000.00 PDF Format
Supply Ability:20
Port:SHENZHEN
share:
  • Product Introduction
  • Consulting
  • Model NumberFC-9624YL
    Brand NameYM
    Payment TermsT/T western union paypal
    Introduction:
    FC-9624YL(Distributive refrigerated type)Automatic Water Sampler is an environmental monitoring instrument that use to online-auto-sample pollutant source. It use special pump for sewage to pumping with big diameter and high flow speed that could avoid pump blockage availably.According to user needs, it could arbitrarily set sample method, delay time, sample quality and position of save, that is controlled by high performance industrial "ARM" controller for 32 bits. It can sampling with auto-online-detection instruments(For example, online COD, Ammonia nitrogen, total phosphorus-total nitrogen, heavy metal, etc.)at same time for contrast with those test results. After match with flux sensorit can do both measure sewage and sample as flux ratio. It could link with other online detection instruments to save exceeded sample.According to needs, it could to launch sample order randomly by wireless remote control. Therefore, our sampler could get most real and impactful water sample.It is one of requisite instrument for more effective, less work, and ensures accuracy and availability of data who work for environmental monitoring.
     Main function indicators:
    (1) Sample method:
    * Standard sample:
        Delay of sample:(1~9999min)for set. Increment is 1 min.
    Interval of sample:(1~9999min)for set. Increment is 1 min.
    Sample amount:50~1000ml for set. Increment is 1 ml.
    Mixed sample:
        Delay of sample:(1~9999min)for set. Increment is 1 min.
    Interval of sample:(1~9999min)for set. Increment is 1 min.
    Sample amount:50~1000ml for set. Increment is 1 ml.
      Number of mixed sample:(1~20)
    Parallel sample:
        Delay of sample:(1~9999min)for set. Increment is 1 min.
    Interval of sample:(1~9999min)for set. Increment is 1 min.
    Sample amount:50~1000ml for set. Increment is 1 ml.
      Number of parallel sample:(1~24)
    * Flowmeter control sample:
    Dedicatedflowmeter control sample.
    1~9999 pulses for set. Increment is 1 pulse. Output pulse should be 5V~15V positive pulse.
    * Output flowmeter control sample
    1~9999 pulses for set. Increment is 1 pulse. Output pulse should be 5V~15V positive pulse.
    (2)Flow characteristic of peristaltic pump:3700ml/min,Internal diameter 10mm,High strength silicone  tube
    (3)Error of sampling quantity:±5%
    (4)Accuracy of sample retry:±5ml.
    (5)Vertical range:8m.
    (6)Horizontal range: 50m, the sample tube has auto-wash function.
    (7)Water container:24 polyethylene bottles for 1000ml.
    (8)Error of timing control:δ1≤0.1% and δ12≤30S.
    (9)Airtightness of piping system: ≤-0.05MPa.
    (10)Mean time between failure: ≥3000h/time.
    (11)Insulation resistance: >20MΩ.
    (12)2.8TFT colorful liquid crystal display,it use Human-computer dialogue.
    (13)Software lock, it could to protect programs from modification.
    (14)It could preset and save maximum 10 programs for using according to sample demands.
    (15)Sampler could auto-record and save sampling for each time. After match with flowmeter, the record capacity is about to record half year for each data per 5 minutes. Data have 2 types: instantaneous flux and integrated flux. Each data conclude: mouth, day, minute. Each flux data group of time interval could be arbitrarily set. New data will replace old data when no space. Instantaneously cut power source can’t miss data. User could use these data and sample test results to analysis.
    (16)Temperature for keep sample:0~8 (Controllable),Error of thermostat:±2
    (17)Temperature for work:-5 to +50
    (18)Power Source:AC220V±10%
    (19)Dimensions:500mm´560mm´960 mm (Length´Width´Height).
    (20)Weight:50Kg



  • Introduction:

    FC-9624YL(Distributive refrigerated type)Automatic Water Sampler is an environmental monitoring instrument that use to online-auto-sample pollutant source. It use special pump for sewage to pumping with big diameter and high flow speed that could avoid pump blockage availably.According to user needs, it could arbitrarily set sample method, delay time, sample quality and position of save, that is controlled by high performance industrial "ARM" controller for 32 bits.
