Features: 1. The surface temperature accurately even. Used in the design of large areas of the whole piece of copper plate as temperature control plate, to improve the surface temperature of the tested sample consistency. 2. Advanced control system. To quickly and stable temperature control. 3. The friendly man-machine interface. Cold, hot plate temperature and heat flux are intuitive power by the time the LCD display. 4. Simple operation. Electric mobile plywood, liquid crystal display with adjustable clamping force, automatically shut down insulation door sample after installed. 5. Intelligent data processing. Highly automated computer data communication and report processing system, plate thermal conductivity apparatus with computer communication interface, real-time display temperature curve. 6. Automatic generation of test reports and print. Software built-in test record, data processing and report formats, automatically Technical parameters: 1. The maximum test piece dimensions. Length * width * thickness: 300 * 300 * 50 mm 2. The temperature control precision: 0.05 ℃ 3. Resolution: 0.01 ℃ 4. The biggest hot plate set temperature: 80 ℃ 5. Cold plate minimum set temperature: room temperature 6. Measuring accuracy: 3% 7. The coefficient of thermal conductivity measurement range: 0.010 ~ 5.000 w (k.m) 8. Power supply: AC 220 v
Features: 1. The surface temperature accurately even. Used in the design of large areas of the whole piece of copper plate as temperature control plate, to improve the surface temperature of the tested sample consistency. 2. Advanced control system. To quickly and stable temperature control. 3. The friendly man-machine interface. Cold, hot plate temperature and heat flux are intuitive power by the time the LCD display.
