BIX-8815 Raman Spectroscopy Testing System

Product ID：FGlm101

Price: Please inquire PDF Format

Supply Ability:50 SETS/MON

Port:SHENZHEN

Product Introduction
Other information

Model NumberBIX-8815

Brand NameHZBOYUAN

Payment TermsTT，PAYPAL，Alibaba.com Pay

BIX-8815 Raman Spectroscopy Testing System
Introduction:
Raman spectroscopy is a powerful analytical technique in molecular spectroscopy, based on inelastic light scattering. When incident light interacts with a sample, molecular vibrations cause energy shifts in the scattered photons, resulting in a Raman spectrum. Since each substance has a unique vibrational fingerprint, Raman spectroscopy enables precise qualitative identification of unknown samples. Furthermore, the linear relationship between the intensity of Raman peaks and molecular concentration allows for accurate quantitative analysis. The application scope of Raman spectroscopy testing systems includes: identification of jewelry, cultural relics, and valuable items; rapid detection of fruits, vegetables, and other foods; detection and analysis of drug components; chemical and environmental monitoring and supervision, among other fields.
Features:
1. Non-contact and non-destructive - applicable to both liquid and solid samples, and not subject to physical interference.
2. High specificity - Unique spectral fingerprints enable precise material identification.
3. Wide applicability - applicable to organic/inorganic compounds, polymers, drugs, etc.
4. Wide spectral range, up to 4000 cm-1
5. High resolution, with a maximum of <8cm-1
6. The laser line width is adjustable, and the output power is adjustable
7. Modular design, flexible testing
Technical Specifications:

model	BIX-8815-532-01 Basic Model BIX-8815-532-02 High Sensitivity Type	BIX-8815-785-01 Basic Model BIX-8815-785-02 High Sensitivity Type	BIX-8815-830-01 Basic Model BIX-8815-830-02 High Sensitivity Type
laser parameters	Wavelength: 532nm Power ≥ 100mW Line width < 0.1nm	Wavelength: 785nm Power ≥ 400mW Line width < 0.1nm	Wavelength: 830nm Power ≥ 400mW Line width < 0.1nm
Raman spectral range	176cm-1 - 4000cm-1	176cm-1 - 3500cm-1	176cm-1 - 2800cm-1
optical resolution	< 10.5cm-1	< 10cm-1	< 10cm-1
Working focal length of probe	7.5mm	7.5mm	7.5mm
signal-to-noise ratio	[532-01] 600 : 1 [532-02] 800: 1	[785-01] 600: 1 [785-02] 800: 1	[830-01] 600: 1 【 830-02 】 800:1
Laser power supply	110/220 VAC	110/220 VAC	110/220 VAC
Spectrometer interface	USB2.0，12Mbps	USB2.0，12Mbps	USB2.0，12Mbps
humidity	5%-80%	5%-80%	5%-80%
Ambient temperature	0℃ -45℃	0℃ -45℃	0℃ -45℃
