AC300-S-CTM servo glue homogenizer Introduction: The AC300-S-CTM program-controlled servo glue spreader is a high-performance precision glue spreader that adopts advanced design concepts and is equipped with a precise motion control system to achieve high-precision and high uniformity glue blending operations. It can store 100 sets of programs, each with up to 100 steps. All operating parameters such as speed, acceleration, rotation time, and glue dispenser selection can be conveniently set on the touch screen. Technical parameters: High RPM: 5000 RPM Speed resolution: ± 1 RPM Large rotation time: 3000 seconds Rotation time resolution: 0.1 seconds High acceleration: 10000 RPM/S Uniform adhesive sample processing size: 12 inches large (special specifications can be customized) Size: 520mm (W) x750mm (D) x425mm (H) Weight: 30kg Power input: 100-120V, single-phase, 450W (110V type) 200-230V， Single phase, 450W (220V type) Vacuum input requirement: 0.06-0.09Mpa, with a vacuum flow rate of at least 15L/Min Vacuum interface: The outer diameter of the outlet on the back plate of the equipment is 6mm Waste discharge interface: The outer diameter of the outlet on the back panel of the equipment is 16mm
Introduction: The AC300-S-CTM program-controlled servo glue spreader is a high-performance precision glue spreader that adopts advanced design concepts and is equipped with a precise motion control system to achieve high-precision and high uniformity glue blending operations. It can store 100 sets of programs, each with up to 100 steps. All operating parameters such as speed, acceleration, rotation time, and glue dispenser selection can be conveniently set on the touch screen.
