ZNCL-16-PD Digital Magnetic Stirring Heating Mantle

Product Introduction
The ZNCL-16-PD Digital Magnetic Stirring Heating Mantle is a laboratory heating and stirring device designed for heating and magnetic stirring of standard and non-standard reaction vessels. It combines a large-area electric heating mantle with a magnetic stirring system, providing uniform heating, rapid temperature rise and stable stirring.
The heating temperature can reach up to 380°C, while the stepless stirring speed can be adjusted from 60 to 2500 rpm. Depending on the selected model, it is suitable for reaction vessels with capacities ranging from 50 mL to 10,000 mL.
The unit features a corrosion-resistant nano-composite working surface, a German PAPST DC brushless motor, digital speed display and an inclined control panel for convenient operation from both sitting and standing positions.

Performance Features
• Fast and uniform heating: Electric heating mantle provides a large heating area and efficient heat transfer.
• Maximum heating temperature: Up to 380°C.
• Heating and stirring in one unit: Suitable for simultaneous heating and magnetic stirring.
• Wide vessel compatibility: Available for standard and non-standard reaction vessels from 50 mL to 10,000 mL, depending on model.
• German PAPST brushless motor: Stable performance, low noise, long service life and no spark generation.
• Stepless speed control: Smooth low-speed operation and strong high-speed stirring.
• Digital speed display: Real-time display of stirring speed.
• Nano-composite working surface: Corrosion-resistant, acid- and alkali-resistant and easy to clean.
• Ergonomic control panel: The 30° inclined panel provides a comfortable viewing angle for both seated and standing operation.
• Continuous operation: Designed for long-term laboratory operation.

Working Principle
The Digital Magnetic Stirring Heating Mantle combines electric heating and magnetic stirring.
During heating, the electric heating element transfers heat through the heating mantle and working surface to the reaction vessel, providing a relatively large and uniform heating area. The heating system enables rapid temperature rise and a maximum temperature of 380°C.
For stirring, the built-in DC brushless motor drives a magnetic coupling system. A magnetic stir bar placed inside the reaction vessel rotates under the magnetic field, producing continuous liquid circulation and mixing.
The stirring speed is continuously adjustable from 60 to 2500 rpm, allowing users to select an appropriate stirring speed according to the viscosity and volume of the sample.

Technical Parameters

Parameter	Specification
Model	ZNCL-16-PD
Product Type	Digital Magnetic Stirring Heating Mantle
Working Surface Diameter	Ø150 / Ø200 / Ø250 / Ø300 mm
Power Supply	AC 220 V, 50 Hz
Optional Export Power Supply	110 V, 60 Hz
Working Surface Material	Nano-composite material
Maximum Heating Temperature	380°C
Stirring Speed	60–2500 rpm
Timer Range	0–999 min
Motor	40 W DC Brushless Motor
Vessel Capacity	50–1000 mL / 50–2000 mL / 50–5000 mL / 50–10,000 mL
Speed Display	Digital
Control Panel	30° inclined panel
Operating Mode	Continuous operation

Dimensions and Weight

Working Surface	Overall Dimensions	Package Dimensions	Weight
Ø150 mm	325 × 215 × 120 mm	315 × 205 × 170 mm	2200 ± 200 g
Ø200 mm	325 × 215 × 120 mm	375 × 265 × 170 mm	4000 ± 200 g
Ø250 mm	430 × 270 × 150 mm	480 × 320 × 200 mm	7000 ± 200 g
Ø300 mm	500 × 330 × 150 mm	550 × 380 × 200 mm	9500 ± 200 g

Applications
The ZNCL-16-PD Magnetic Stirring Heating Mantle is suitable for heating, mixing and reaction processes in:
• Chemical laboratories
• Pharmaceutical laboratories
• Universities and research institutes
• Biological and life science laboratories
• Material science laboratories
• Petrochemical laboratories
• Food and beverage laboratories
• Quality control laboratories
• Industrial R&D departments
Typical applications include sample preparation, dissolution, mixing, chemical reactions, heating experiments and laboratory synthesis.

ZNCL-16-PD vs. Conventional Heating Equipment

Feature	ZNCL-16-PD	Conventional Heating Equipment
Heating	Electric heating mantle	Heating plate or external heating
Stirring	Integrated magnetic stirring	Often requires separate stirrer
Maximum Temperature	Up to 380°C	Model dependent
Stirring Speed	60–2500 rpm	Not always available
Speed Adjustment	Stepless	Limited or manual
Speed Display	Digital	Often unavailable
Working Surface	Nano-composite	Material dependent
Motor	DC brushless motor	Conventional motor
Vessel Capacity	50–10,000 mL, model dependent	Model dependent
Operation	Heating + stirring integrated	May require multiple devices

The main advantage of the ZNCL-16-PD Digital Magnetic Stirring Heating Mantle is its integrated heating and stirring design. It combines high-temperature heating, stepless magnetic stirring and digital speed indication in one laboratory instrument, reducing equipment requirements and simplifying experimental operation.

Frequently Asked Questions (FAQ)
1. What is the ZNCL-16-PD used for?
The ZNCL-16-PD is used for heating and magnetic stirring of laboratory samples and reaction solutions, including mixing, dissolution and chemical reaction processes.
2. What is the maximum heating temperature?
The maximum heating temperature is 380°C.
3. What is the stirring speed range?
The stirring speed can be adjusted continuously from 60 to 2500 rpm.
4. What vessel capacities are supported?
Depending on the working surface size, the equipment can accommodate reaction vessels ranging from approximately 50 mL to 10,000 mL.
5. Does the ZNCL-16-PD have a digital speed display?
Yes. The instrument provides a digital display of stirring speed for convenient operation and monitoring.
6. What type of motor does the instrument use?
It uses a 40 W DC brushless motor, offering stable operation, low noise, long service life and spark-free operation.
7. Is the working surface resistant to corrosion?
Yes. The working surface uses nano-composite material, which provides corrosion resistance, acid and alkali resistance and easy cleaning.
8. Can the ZNCL-16-PD operate continuously?
Yes. The instrument is designed for continuous operation, making it suitable for extended laboratory heating and stirring processes.
