WKTS-RC500Y Differential Scanning Calorimeter

Product ID：WLcs058

Price: Please inquire PDF Format

Supply Ability:50 SETS/MON

Port:SHENZHEN

Product Introduction
Other information

Model NumberWKTS-RC500Y

Brand NameTZKETUO

Payment TermsTT，PAYPAL，Alibaba.com Pay

WKTS-RC500Y Differential Scanning Calorimeter
Introduction:
The WKTS-RC500 series differential scanning calorimeter is equipped with an embedded industrial computer and a seven inch industrial touch LCD display screen. It can directly test the oxidation induction period time and export the oxidation induction period experimental map and data through a USB flash drive. WKTS-RC500 can be connected to a computer through a network data cable, and the instrument can test the melting point, melting temperature, and oxidation induction period time after connecting to the computer.
Application areas:
Measure physical and chemical changes related to heat, such as melting point, melting temperature, oxidation induction period, etc. Differential scanning calorimeter is widely used in fields such as plastics, rubber, coatings, food, medicine, biological organisms, inorganic materials, metal materials, and composite materials.
characteristic:
1. Easy to operate, one click automatic testing
2. Embedded industrial computer for direct testing of oxidation induction period time
3. Export the experimental graph of oxidation induction period through USB drive
4. Dual temperature probes ensure high precision and repeatability
5. The experimental process does not require personnel supervision
6. Digital gas mass flowmeter automatically switches between two gas flow rates
7. Seven inch large screen LCD display, with clear graphs and curves at a glance
8. One click switching between Chinese and English
Technical Parameter

PRODUCT MODEL	WKTS-RC500R	WKTS-RC500Y	WKTS-RC500A
measuring range	melting point	Oxidation Induction Period (OIT)	Melting point, oxidation induction period, glass transition temperature, enthalpy change
range	0～±200mW
temperature range	Room temperature~500 ℃
heating rate	0.1～50℃/min
Temperature resolution	0.01℃
Temperature Accuracy	±0.1℃
Temperature repeatability	±0.1℃
accuracy	±2%
resolution	0.001mW
Resolution	0.001mW
Temperature control mode	Full process automatic control
Curve scanning	Heating up scan
atmosphere control	Gas mass flowmeter
Display mode	24 bit color, 7-inch touch screen
Working power supply	AC220V 50Hz/60Hz
Size (w * d * h)	463527cm
Net weight	14.5KG
Packaging size (w * d * h)	584540cm
gross weight	18KG

Introduction:
The WKTS-RC500 series differential scanning calorimeter is equipped with an embedded industrial computer and a seven inch industrial touch LCD display screen. It can directly test the oxidation induction period time and export the oxidation induction period experimental map and data through a USB flash drive. WKTS-RC500 can be connected to a computer through a network data cable, and the instrument can test the melting point, melting temperature, and oxidation induction period time after connecting to the computer.
