SIM-3003 Series Reflective Photometric Integrating Sphere

Product ID：GSYqt036

Price: Please inquire PDF Format

Supply Ability:50 SETS/MON

Port:SHENZHEN

Product Introduction
Other information

Model NumberSIM-3003

Brand NameHZBOYUAN

Payment TermsTT，PAYPAL，Alibaba.com Pay

SIM-3003 Series Reflective Photometric Integrating Sphere
Introduction:
Compared to a radiance integrating sphere, a reflectance integrating sphere features an additional 8-degree inclined light inlet at the bottom for connecting to the light source. This allows light from a standard light source to directly illuminate the sample port on the top of the integrating sphere. After contacting the sample surface, the standard light will be reflected back into the integrating sphere, where the reflected light can be measured and analyzed through other measurement ports. When combined with a spectrometer, fiber optics, light source, and various optical measurement devices, the reflectance integrating sphere can form a system for measuring the surface reflectance of different samples, including planar and curved irregular samples.
Application scope:
Illumination optics, laser technology
Fiber optics, material analysis
Fields such as biochemical medical technology
Measure the reflective properties of materials
Features:
1. Compact and compact structural design
2. Multiple SMA905 fiber optic interfaces
3. Vertical optical path 8° design
4. The output port is a 90° vertical integrating sphere output
Technical Specifications:

model	SIM-3003-03001	SIM-3003-02501	SIM-3003-03801	SIM-3003-05001
ball diameter	30mm	1 inch	1.5 inches	2 inches
Overall dimensions	Φ49 ×42mm	Φ44 ×37.5mm	Φ57×50.5mm	Φ70×63mm
Light inlet	At the bottom, equipped with a fiber optic adapter
Sample port	Top, with customizable size
inspection port	Side, with fiber optic adapter
coating material	PTFE
spectral range	250~2500nm

SIM-3003 Series Reflective Photometric Integrating Sphere
Introduction:
Compared to a radiance integrating sphere, a reflectance integrating sphere features an additional 8-degree inclined light inlet at the bottom for connecting to the light source. This allows light from a standard light source to directly illuminate the sample port on the top of the integrating sphere. After contacting the sample surface, the standard light will be reflected back into the integrating sphere, where the reflected light can be measured and analyzed through other measurement ports. When combined with a spectrometer, fiber optics, light source, and various optical measurement devices, the reflectance integrating sphere can form a system for measuring the surface reflectance of different samples, including planar and curved irregular samples.
