Introduction: MSK-AFA-IV small coating machine adopts the organic combination of electrical control and mechanics, which can save a lot of raw materials, improve process technology, facilitate accurate coating on different substrates, reduce and eliminate the different coating speeds and pressures. The error caused by human factors. Mainly used for plastics, paper, film production test, can also be used for other related coating, coating industry. Features: 1. Adjust the coating thickness by changing the coating roller. 2. Adjust the coating speed with the knob. 3, using imported components. 4, uniform coating. Technical Parameters: Power supply: 220V 50Hz Power:50W Coating speed: 1mm/min-1200mm/min adjustable Coating area: 420mm×350mm Coating thickness: 12μm-200μm (depending on the coating roller used) Roller: Ø12mm×40mm Size: 580mm × 340mm × 100mm; Weight: 20kg Installation conditions: This equipment is required to be used at altitudes below 1000m, temperature 25°C±15°C, and humidity 55%Rh±10%Rh. 1, water: no 2, electricity: AC220V; 50Hz, must have a good ground 3, gas: no 4、Workbench: size 800mm×600mm×700mm, load-bearing more than 200kg 5, ventilation device: no Optional accessories: 1, can be customized to adjust the thickness of the film applicator, the minimum thickness of 5μm, adjustment accuracy of 1μm. 2. The coating film thickness is 12μm, 15μm, 20μm, 25μm, 30μm, 40μm, 50μm, 60 μm, 80 μm, 100 μm, 120 μm, 150 μm, 200 μm coating rolls.
Introduction: MSK-AFA-IV small coating machine adopts the organic combination of electrical control and mechanics, which can save a lot of raw materials, improve process technology, facilitate accurate coating on different substrates, reduce and eliminate the different coating speeds and pressures. The error caused by human factors. Mainly used for plastics, paper, film production test, can also be used for other related coating, coating industry.
