| Detector | |
| Detector Type | Focal plane array, uncooled microbolometer |
| Resolution | 384×288 |
| Spectral band | 8~14μm |
| Imaging Performance | |
| Field of view | See “Optional lens Index” below |
| Spatial resolution | |
| Focus | Manual/automatic |
| Thermal sensitivity(NETD) | See “Temperature & NETD Index” below |
| Max frame rate | 50Hz |
| Imaging Display | |
| LCD | 3.5’ touchscreen LCD, VGA(640*480) |
| Measurement | |
| Temperature measurement range | See “Temperature & NETD Index” below |
| Accuracy | |
| Temperature Measurement Mode | moveable spotmeter, line/area measurement, max temperature point tracking |
| Measurement correction | Emissivity correction, background temperature correction, optical filter/window correction, atmosphere transmission correction |
| Automatic alarming | User defined alarming threshold |
| Palette | 10 Palettes: including grayscale, grayscale inverted, ironbow, hot metal, etc. |
| Display enhancement | Automatic/manually image stretching, image brightness and contrast adjustment |
| Visual camera | 5MP industry performance visual camera |
| Infrared/Visible light display mode | Full screen infrared/ full screen visible light/pic-in-pic/thermal fusion/color alarm |
| Image and data storage | |
| Storage medium | Micro SD Memory Card |
| File format | Temperature data: self defined .mgt format. Video: 264 format |
| Annotation | 180s voice annotation, text annotation |
| Environmental | |
| Operating Temperature | -10℃~+50℃ |
| Storage Temperature | -20℃~+60℃ |
| Humidity | <85%(Un-condensing) |
| Enclosure rating | IP54 |
| Physical characteristics | |
| Power supply | Ion rechargeable battery, 6+ hours continuous use |
| Laser poiter | 3.5mw/650nm |
| Dimension | 205mm(L)×101mm(W)×234mm(H) (25mm lens included) |
| Weight | 0.58kg (25mm lens included) |
| Signal interface | USB2.0 |
| Audio output | Support |
| Accessory | Infrared lens, AC adapter, Software disk, User manual |
| Focus | FOV | Spatial resolution | Detect/distinguish/identity distance of human | Detecet distance of vehicle |
| 15mm | 36o×27o | 1.7 mard | 340m/84m/42m | 860m |
| 25mm | 22o×16.5o | 1.0 mrad | 560m/140m/70m | 1400m |
| 40mm | 13o×10o | 0.6 mrad | 900m/220m/110m | 2300m |
| 65mm | 8.4o×6.3o | 0.4 mrad | 1400m/370m/180m | 3700m |
