| Detector | |
| Detector type | Uncooled focal plane array microbolometer |
| Spectral band | 7.5~14μm |
| Resolution | 384×144 |
| Pixel pitch | 17μm |
| Max frame rate | 100Hz |
| Measurement And Imaging Performance | |
| Temperature ranges | See “Temperature & NETD Index” below |
| Accuracy | |
| Thermal sensitivity(NETD) | |
| Field of view | See “Optional lens Index” below |
| Spatial resolution | |
| Focus | Manual/automatic |
| Minimum focus distance | 0.3m |
| Radiance correction | Emissivity adjustable range: 0.01~1.0 |
| Background temperature correction | Auto correction by user background temperature input |
| Optical filter/Window correction | Auto correction by user transmission input |
| Palette | 10 Palettes: including grayscale, grayscale inverted, ironbow, hot metal, etc. |
| Digital zoom | 2X, 4X |
| Data Storage | |
| Report Generation | Word format wiht content selectable wizard |
| Thermal image storage | BMP format. With/without tag information optional |
| Video storage | MPEG format compression. With/without user tag information. Maxmum size settable |
| Log storage | Auto record, auto preservation |
| Ethernet | |
| Signal interface | 100M Ethernet, supported protocols: RTSP, ONVIF, HTTP, FTP, TCP, UDP, IP, DHCP, ARP, ICMP |
| IP assignment | Dynamic IP / static IP selectable. DHCP server integrated at control terminal |
| Networking mode | Direct connection / connection through LAN |
| Environmental | |
| Operating Temperature | -30~60℃ |
| Storage Temperature | -40~80℃ |
