JC60X95 Laboratory Jaw Crusher

Position: Home > > Lab general equipment > Crushing equipment > Crushing apparatus > JC60X95 Laboratory Jaw Crusher

JC60X95 Laboratory Jaw Crusher

Product ID：SYFSfs041

Price: Please inquire PDF Format

Supply Ability:50 SETS/MON

Port:SHENZHEN

Product Introduction
Other information

Model NumberJC60X95

Brand NameCSTIANCHUANG

Payment TermsTT，PAYPAL，Alibaba.com Pay

JC60X95 Laboratory Jaw Crusher
Product Introduction
The JC60X95 Laboratory Jaw Crusher is a compact laboratory crushing machine designed for the coarse and fine crushing of ores and brittle materials. It is mainly used for materials with a feed particle size of less than 35 mm and allows the discharge particle size to be adjusted according to different experimental requirements.
The JC60X95 can perform both coarse crushing and fine crushing by adjusting the crushing gap. Different jaw plate materials, including high manganese steel, zirconia and cemented carbide, can be selected according to material hardness, chemical properties and contamination requirements.
With variable-speed control, touchscreen operation, adjustable crushing parameters and multiple safety protection features, the JC60X95 is suitable for sample preparation and material testing in university laboratories, research institutions, mining laboratories and industrial laboratories.

Product Applications
The JC60X95 Laboratory Jaw Crusher is suitable for crushing a wide range of ores, rocks and brittle materials.
Mining and Geology
• Limestone
• Calcium carbide
• Calcium carbide slag
• Shale
• Basalt
• River pebbles
• Bluestone
• Various mineral ores
Industrial Applications
• Mining
• Metallurgy
• Chemical industry
• Building materials
• Water conservancy
• Transportation
• New energy materials
• Geological and mineral analysis
The crusher is particularly suitable for laboratory sample preparation, preliminary crushing and fine crushing before further analysis or processing.

Performance Features
• Adjustable Discharge Size: The crushing gap can be adjusted according to the required final particle size, allowing both coarse and fine crushing operations.
• Quick Jaw Plate Replacement: The feed cover can be opened to provide convenient access to the jaw plates for replacement and maintenance.
• Reversible Jaw Plates: When one side of the jaw plate becomes worn, the plate can be turned over for continued use, helping extend service life.
• Multiple Jaw Plate Materials: High manganese steel, zirconia and cemented carbide jaw plates are available to accommodate different material characteristics and contamination requirements.
• Variable-Speed Control: The integrated variable-frequency drive allows the jaw plate operating speed to be adjusted according to material properties and crushing requirements.
• Touchscreen Operation: The touchscreen allows users to set operating time and jaw plate speed for convenient operation and improved process repeatability.
• Reduced Material Rebound and Dust: The specially designed feed inlet helps reduce material rebound during feeding and minimizes dust generation.
• Safety Interlock Protection: The feed cover and hopper are equipped with travel-switch protection. Opening the relevant protective components automatically cuts off power to improve operator safety.
• Compact Laboratory Design: The compact structure and approximately 105 kg weight make the equipment suitable for university laboratories, research institutions and industrial laboratory environments.

Working Principle
The JC60X95 Laboratory Jaw Crusher operates through the relative movement between a fixed jaw plate and a movable jaw plate.
When the motor drives the crushing mechanism, the movable jaw periodically approaches and moves away from the fixed jaw. Material entering the crushing chamber is compressed, crushed and broken by the mechanical force generated between the two jaw plates.
After repeated crushing, material smaller than the selected discharge opening passes through the crushing chamber and is discharged from the bottom.
The crushing gap can be adjusted according to the required output particle size, allowing the JC60X95 to be used for both coarse crushing and fine crushing.

Crushing Materials
The JC60X95 can be used for a variety of ores and brittle materials, including:
• Limestone
• Calcium carbide
• Calcium carbide slag
• Shale
• Basalt
• River pebbles
• Bluestone
• Mineral ores
• Other brittle materials
The appropriate jaw plate material should be selected according to material hardness, chemical composition and required contamination control.

Technical Parameters

Parameter	Specification
Model	JC60X95
Motor Power	0.75 kW
Power Supply	Single-phase 220 V, 50 Hz
Jaw Crushing Speed	560 rpm
Control Method	Touchscreen
Production Capacity	50 kg/h, depending on material bulk density
Feed Particle Size	<35 mm
Discharge Particle Size	≤8 mm, adjustable
Jaw Plate Materials	High manganese steel, zirconia, cemented carbide
Dimensions	Approx. 690 × 510 × 590 mm
Weight	Approx. 105 kg

Jaw Plate Material Options
Different jaw plate materials can be selected according to the characteristics of the material being crushed.
• High Manganese Steel: Suitable for general-purpose ore and rock crushing applications requiring high mechanical strength and wear resistance.
• Zirconia: Suitable for applications where reduced metal contamination is important, particularly for certain high-purity laboratory materials.
• Cemented Carbide: Suitable for hard and abrasive materials requiring high wear resistance.
The appropriate jaw plate material should be selected based on material hardness, chemical properties, target application and required contamination control.

JC60X95 vs. Conventional Laboratory Jaw Crushers

Feature	JC60X95 Laboratory Jaw Crusher	Conventional Laboratory Jaw Crusher
Crushing type	Jaw crushing	Jaw crushing
Feed particle size	<35 mm	Depends on model
Discharge particle size	≤8 mm, adjustable	Depends on model
Speed control	Variable-frequency control	Depends on configuration
Operation	Touchscreen	Conventional controls may be used
Jaw plate options	Manganese steel, zirconia, cemented carbide	Depends on configuration
Jaw plate replacement	Quick replacement design	Depends on structure
Jaw plate reversal	Supported	Depends on design
Safety protection	Travel-switch interlock	Depends on configuration
Typical application	Laboratory sample preparation and ore crushing	General laboratory crushing

Frequently Asked Questions
1. What is the JC60X95 Laboratory Jaw Crusher used for?
The JC60X95 is mainly used for crushing ores, rocks and brittle materials in laboratory sample preparation. It can perform coarse and fine crushing according to the selected discharge size.
2. What is the maximum feed particle size?
The specified feed particle size is less than 35 mm.
3. What is the final discharge particle size?
The discharge particle size can be adjusted to ≤8 mm according to the crushing gap and material characteristics.
4. Can the JC60X95 crush hard ores?
Yes. The crusher can be equipped with different jaw plate materials, including high manganese steel and cemented carbide, to accommodate different material hardness levels.
5. What jaw plate materials are available?
The available jaw plate materials include high manganese steel, zirconia and cemented carbide.
6. Can the jaw plate speed be adjusted?
Yes. The JC60X95 is equipped with a variable-frequency drive, allowing the jaw plate operating speed to be adjusted according to application requirements.
7. How is the crusher operated?
The equipment uses a touchscreen control system. Users can set operating time and jaw plate speed through the touchscreen.
8. How do I replace the jaw plates?
The feed cover can be opened to provide convenient access to the jaw plates. When one side of a jaw plate becomes worn, it can be turned over for continued use.
9. What safety features does the JC60X95 have?
The feed cover and hopper are equipped with travel-switch protection. When the protective components are opened, the machine automatically cuts off power to reduce operating risks.
10. What is the production capacity of the JC60X95?
The rated production capacity is approximately 50 kg/h, although actual capacity depends on the bulk density and characteristics of the processed material.

Product Positioning
The JC60X95 Laboratory Jaw Crusher is a compact and flexible laboratory crushing machine for ores, rocks and brittle materials. With adjustable discharge size, variable-frequency speed control, touchscreen operation, interchangeable jaw plates and safety interlock protection, it provides an efficient solution for laboratory sample preparation in mining, metallurgy, geology, chemical engineering, building materials, new energy and research applications.

Frequently Asked Questions
1. What is the JC60X95 Laboratory Jaw Crusher used for?
The JC60X95 is mainly used for crushing ores, rocks and brittle materials in laboratory sample preparation. It can perform coarse and fine crushing according to the selected discharge size.
2. What is the maximum feed particle size?
The specified feed particle size is less than 35 mm.
3. What is the final discharge particle size?
The discharge particle size can be adjusted to ≤8 mm according to the crushing gap and material characteristics.
4. Can the JC60X95 crush hard ores?
Yes. The crusher can be equipped with different jaw plate materials, including high manganese steel and cemented carbide, to accommodate different material hardness levels.
5. What jaw plate materials are available?
The available jaw plate materials include high manganese steel, zirconia and cemented carbide.
6. Can the jaw plate speed be adjusted?
Yes. The JC60X95 is equipped with a variable-frequency drive, allowing the jaw plate operating speed to be adjusted according to application requirements.
7. How is the crusher operated?
The equipment uses a touchscreen control system. Users can set operating time and jaw plate speed through the touchscreen.
8. How do I replace the jaw plates?
The feed cover can be opened to provide convenient access to the jaw plates. When one side of a jaw plate becomes worn, it can be turned over for continued use.
9. What safety features does the JC60X95 have?
The feed cover and hopper are equipped with travel-switch protection. When the protective components are opened, the machine automatically cuts off power to reduce operating risks.
10. What is the production capacity of the JC60X95?
The rated production capacity is approximately 50 kg/h, although actual capacity depends on the bulk density and characteristics of the processed material.
