FET-2021X Handheld Eddy Current Rotating Scanner Introduction: The FET-2021X handheld eddy current rotary scanner is a new generation of intelligent detection equipment, with continuously adjustable rotational speed and selectable forward and reverse rotation directions. The use of slip ring conductors ensures the transmission of detection signals. The scanner can be equipped with various types of detection probes such as differential, reflective, and orthogonal, and can be matched with various types of eddy current impedance planar instruments. characteristic: FET-2021X is suitable for pre service or in-service scanning and positioning detection of single-layer bolt holes and small cracks in internal threads, especially for regular inspection of aerospace components. Technical parameters: Speed range: 10-240 rpm continuously adjustable Rotation direction: selectable by forward/reverse button switch Probe signal power supply method: rotating slip ring power supply Probe Connection: Standard Q8 Rod Pulling Interface Instrument end: 7-core, connected to the instrument through an adapter Drive probe diameter range: 4-32mm Rated working voltage of scanner: 15V Power supply method: It can be powered by the instrument or by an external power supply Scanner size: 100mm (length) x 50mm (width) x 24mm (height) Weight: 255g (net weight) Working temperature: -15~55 ℃ Storage temperature: -20~60 ℃ Relative humidity: not exceeding 85% Working voltage: AC220 ± 10V
Introduction: The FET-2021X handheld eddy current rotary scanner is a new generation of intelligent detection equipment, with continuously adjustable rotational speed and selectable forward and reverse rotation directions. The use of slip ring conductors ensures the transmission of detection signals. The scanner can be equipped with various types of detection probes such as differential, reflective, and orthogonal, and can be matched with various types of eddy current impedance planar instruments.
