| project | Technical Specifications | |
| Infrared basic parameters | detector type | Uncooled focal plane micro-thermal type |
| infrared resolution | 640×512 | |
| superpixel | 1280×1024 | |
| Thermal sensitivity | ≤0.03℃@30℃ | |
| wavelength range | 7-14μm | |
| Infrared field of view angle | 25°×19°/0.2m | |
| spatial resolution | 0.67mrad | |
| frame rate | 60Hz | |
| focus | Manual/Automatic/Electric/Laser/Touchscreen/Continuous | |
| Built-in visible light camera | 13 million pixels, CMOS module, built-in dual LED fill light | |
| digital zoom | 1-40x continuous digital zoom | |
| Basic parameters of sound and image | acoustic sensor | 162 high-sensitivity digital MEMS ultrasonic microphones |
| detection distance | 0.3m~130m | |
| Acoustic field of view angle | 70° (diagonal) | |
| dynamic range | 26dB~132dB | |
| Acoustic refresh rate | ≥25FPS | |
| Sound sampling | 200kHz | |
| Thermal imaging measurement | Temperature measurement range | -40℃ to +650℃, extendable to 2000℃. |
| Temperature measurement accuracy | Within the range of 0~150℃: ±1℃ or ±1% (whichever is greater in absolute value) Other ranges: ±2℃ or ±2% (whichever is greater in absolute value) |
|
| Measurement Mode | Real-time temperature measurement with 10 movable points, 10 movable areas (maximum temperature capture, minimum temperature capture, average temperature measurement), 10 movable lines for temperature measurement, isothermal analysis, temperature difference measurement, and temperature alarm (sound, color). | |
| Global temperature correction | Support the correction of temperature measurement parameters such as emissivity, ambient temperature, reflected temperature, relative humidity, target distance, and infrared window (temperature and transmittance) | |
| Acoustic imaging measurement | frequency range | 2kHz～100kHz |
| Measurement Mode | Single/Multiple sound sources (up to 10 supported), supports regional focusing, and blocks external interference | |
| positioning deviation | ≤1° | |
| Detection Mode | Partial discharge detection mode, gas leakage detection mode, industrial abnormal noise detection mode, sensitive detection mode | |
| image display | LCD (Liquid Crystal Display) | 5” color LCD capacitive touch screen |
| image display | Infrared mode, visible light mode, fusion mode, picture-in-picture mode, sound and image mode, sound and heat mode, heat and sound mode | |
| palette | 11 color palettes to choose from (including Iron Red, Rainbow, Black and White, Black and White Inverted, etc.) | |
| image processing | Automatic/manual adjustment of contrast and brightness, automatic enhancement mode | |
| digital doubling | Infrared: 1-40x continuous digital zoom Acoustic: 1-40x digital zoom |
|
| Shooting and storage | digital camera | Thermal imaging: 13 million pixels, industrial-grade digital camera. Acoustic imaging: 13 million pixels, industrial-grade digital camera |
| storage | Built-in 128G storage and external 32G SD card (expandable) | |
| storage method | Manual/automatic photo or video recording | |
| Image and video formats | JPG (infrared, visible light, fusion, audio and video) MP4 (non-full radiation video) DLV (full radiation video) |
|
| annotation | Voice annotation: Supports 180-second voice recording, stored alongside images (with a built-in microphone, capable of recording and playback via Bluetooth) Text annotation: Supports keypad input Sketch annotation: Supported |
|
| Intelligent diagnosis and analysis | Acoustic diagnosis and analysis | Support time-domain analysis, spectral analysis, partial discharge pattern diagram (PRPD diagram) of signals, as well as functions for discharge type judgment and gas leakage analysis |
| Native analysis | Supports analyzing infrared images and generating infrared reports locally | |
| backend software | It supports functions such as one-click batch report generation, customizable report templates, temperature measurement curves, temperature histograms, and temperature data export | |
| Intelligent Inspection | Ledger establishment + automatic naming + batch import + batch diagnosis + batch report generation | |
| power system | Battery Type | Lithium battery, rechargeable |
| Battery working time | 3 hours of continuous work | |
| Charging type | Smart charger charging or random charging (via AC power adapter or 12V car power supply) | |
| weight | ≤1.7kg (including battery and standard lens) | |
| tripod | 1/4″-20-UNC | |
| Power Saving Mode | Automatic hibernation, automatic shutdown | |
