CTA Creyo thermoelectric material testing system

Product ID：WLqt018

Price: Please inquire PDF Format

Supply Ability:50 SETS/MON

Port:SHENZHEN

Product Introduction
Other information

Model NumberCTA Creyo

Brand NameBJKERUIOU

Payment TermsTT，PAYPAL，Alibaba.com Pay

CTA Creyo thermoelectric material testing system
Introduction:
This system uses a low-temperature refrigeration unit as the cooling source, without the need for liquid nitrogen/helium, to achieve electrical performance (conductivity/resistivity, thermoelectric potential/Seebeck coefficient) and optional thermal performance (thermal conductivity, thermal expansion coefficient, specific heat, etc.) measurement units for solid materials in the low-temperature range (4K-300K; -269 ℃ - room temperature). The hardware structure includes: sample rack components, insertion tube components, vacuum insulation system, refrigeration unit, shock absorption and heat transfer components, temperature control components, dry pump, helium tank, measurement and control instruments, and data acquisition and processing system. The basic system platform provides low-temperature environments and measurement related software and hardware control centers.
Technical parameters:
Thermal conductivity measurement unit

Measurement range:	0.1 W/ m·K～600 W/m·K
Measurement accuracy:	Better than 5%
Sample size:	Cube: 4 × 4, 6 × 6, 8 × 8, 10 × 10 mm × 2-15mm Cylinder: Φ 4-10 mm × 2-15mm

Resistivity measurement unit

Measurement range:	10 μS/m～10 S/m
Measurement accuracy:	Better than 1%
Sample size:	Length: 4-20mm; Width: 1-3mm; Height: 1-3mm

Seebeck coefficient measurement unit

Measurement range:	1μV/K～1V/K
Measurement accuracy:	Better than 6%
Sample size:	Length: 5-20 mm; Width: 2-3 mm; Height: 2-3 mm

Introduction:
This system uses a low-temperature refrigeration unit as the cooling source, without the need for liquid nitrogen/helium, to achieve electrical performance (conductivity/resistivity, thermoelectric potential/Seebeck coefficient) and optional thermal performance (thermal conductivity, thermal expansion coefficient, specific heat, etc.) measurement units for solid materials in the low-temperature range (4K-300K; -269 ℃ - room temperature). The hardware structure includes: sample rack components, insertion tube components, vacuum insulation system, refrigeration unit, shock absorption and heat transfer components, temperature control components, dry pump, helium tank, measurement and control instruments, and data acquisition and processing system. The basic system platform provides low-temperature environments and measurement related software and hardware control centers.
