Introduction: The BTT-2880R5 laser belt tension meter can quickly measure the belt tension of motors and other machinery. This tension meter measures the natural vibration frequency of the belt through laser emission and reception, and then calculates the belt tension value by combining the input belt quality and free belt length. Features: 1. Using laser sensor, direct measurement, more convenient than mechanical sensor. 2. The size of the split type sensor is small, suitable for measuring in a narrow space. 3. There are two types of sensors, one-piece type and split type, for selection 4. Two different units of metric or imperial system can be used to display the readings. 5. With automatic shutdown function. Technical parameter: Measuring range: 10~500Hz Input range: free section belt length Max 99.99m Belt quality Max 9.999kg/m Digital sampling error: <1% Display error: ±1Hz Total error: <5% Operating temperature range: +10~50°C Transportation temperature range: -5~70°C Display: LCD Physical unit of measurement: Metric system: m, kg/m, N British system: inch, lbs/foot, lbf Optical path measurement distance: 3~20mm Separate sensor can go deep: about 66mm Power supply: 4 AAA batteries Dimensions: Host: 178x72x34mm Sensor: 124x21x12mm Weight (without battery): 180g Standard configuration: host Split sensor Portable carrying case (B04) user's manual
Introduction: The BTT-2880R5 laser belt tension meter can quickly measure the belt tension of motors and other machinery. This tension meter measures the natural vibration frequency of the belt through laser emission and reception, and then calculates the belt tension value by combining the input belt quality and free belt length.
