Introduction: AT-180H8 laser belt tension meter can quickly measure the belt tension of motors and other machinery. This tension meter measures the natural vibration frequency of the belt through laser emission and reception, and then calculates the belt tension value by combining the input belt quality and free belt length. Features: 1. Using laser sensor, direct measurement, more convenient than mechanical sensor. 2. The size of the split type sensor is small, suitable for measuring in a narrow space. 3. Two different units of metric or imperial system can be used to display the readings. 4. With automatic shutdown function. Technical Parameters: Measuring range: 10~800Hz Input range: Belt length of free section Max 99.99m Belt quality Max 9.999kg/m Digital sampling error: <1% Display error: ±1Hz Total error: <5% Operating temperature range: +10~50°C Transportation temperature range: -5~70°C Display: LCD Physical unit of measurement: Metric system: m, kg/m, N British system: inch, lbs/foot, lbf Optical path measurement distance: 3~20mm Separate probe can go deep: about 66mm Power supply: 4x1.5v AAA AAA battery Host size: Host: 140x 70x 31mm Sensor: 124x 21x 12mm Host weight: 130g (without battery)
