Parameter |
Range |
Resolution |
Accuracy |
Sample flow range |
(0.2-1.0)L/min×4 |
0.01L/min |
≤±5% |
Sample time |
99 hours 59 minutes set freely |
1min |
≤±0.2% |
Interval time |
99 hours 59 minutes set freely |
1min |
≤±0.2% |
Sample times |
(1-99)times |
— |
— |
Temperature(inlet) |
(-30~99)℃ |
0.1℃ |
≤±1.0℃ |
Pressure(inlet) |
(-20~0)kPa |
0.01kPa |
≤±2.5% |
barometric pressure |
(50~130)kPa |
0.01kPa |
≤±500Pa |
Noise |
≤55dB(A) |
Dimension |
(LxWxH) 260x300x255mm |
Weight |
about 4kg |
Power supply |
AC220V±10%, 50Hz or DC12V/3A(built-in) |
Consumption |
≤35W(Contains no heater) |
